Study of anatomical variations of foramen ovale and pterygoalar bar with it’s clinical significance



Vaishali Sitaram Kirwale¹, Shivaji B Sukre²*



1Assistant Professor, 2Professor & HOD, Department of Anatomy, Government Medical College Aurangabad, Maharashtra, INDIA.

Email: drsukresb@yahoo.co.in , sweetbanty21@gmail.com



Abstract              Background: The foramen ovale is present in the greater wing of the sphenoid bone. The foramen ovale gives passage to mandibular nerve, lesser petrosal nerve, accessory meningeal artery and emissary vein. The present study gives details of variations of foramen ovale and also the incidence of pterygoalar bar in dry human skulls. Materials and Methods: The present study was carried out by using 112 adult dry human skulls. The skulls were examined from the department of Anatomy, Government Medical College Aurangabad. The skulls were carefully observed for the presence of foramen ovale and it’s variations. The length and width of Foramen ovale was measured using digital vernier calliper. Results: The oval shaped foramen was present in 66.07% of skulls. Almond shaped foramen were observed in 14.28% of skulls and round shaped in 10.72% of cases. D shaped foramen was noted in 7.15% cases whereas 1.78% of skulls showed presence of triangular foramen ovale. The mean length of foramen ovale on right side was 7.52+1.15 mm and 7.29+1.06 mm on left side. The mean width of foramen was 4.18+0.78 mm and 4.28+0.81 mm on right and left side respectively. Conclusion: The present study shows wide anatomical variations in foramen ovale. The different shapes like oval, almond, rounded, D shape, triangular were found and abnormal outgrowth like presence of bony pterygoalar bar, spur were also noted in the present study.

Key Words: Foramen ovale, human skulls, spur, pterygoalar bar



INTRODUCTION

The foramen ovale lie lateral to the Foramen lacerum on infratemporal surface of greater wing of the sphenoid bone. It is present near to the posterior margin of lateral pterygoid plate.1 foramen ovale is located posterior to foramen rotundum, posterior end of carotid groove and just lateral to lingula.2 The foramen ovale transmits the mandibular nerve, lesser petrosal nerve, accessory meningeal branch of maxillary artery and a venous plexus that connects the cavernous sinus to the pterygoid venius plexus in the infratemporal fossa.1,3,4 The mandibular branch of trigeminal nerve passes from the trigeminal ganglion in the cranium through the foramen ovale in the plane of the lateral pterygoid plate. In the foramen ovale it is joined by the entire motor root of the trigeminal nerve and emerges from the skull as a mixed nerve.5 Sphenoid bone ossified by intramembranous and enchondral ossification during 7th month of intrauterine life, the foramen ovale appears as a prominent ring shaped area. The foramen ovale clearly visible 3 year after the birth of the baby.6 The foramen ovale is located at a transition zone between intracranial and extracranial structures.7 It has intense clinical significance in various therapeutic procedures. It gives best neurological information by placing electrodes at foramen ovale during electroencephalography8. Percutaneous biopsy can be done through the foramen ovale in patients with cavernous sinus tumours.9 Study of variations of foramen ovale is very essential in order to treat the patients of trigeminal neuralgia as Gasserion ganglion can be approached transcutaneously through the skull base via foramen ovale.10 The present study provides detailed information regarding variations in shape, size of foramen ovale, morphometric measurements like length and width of foramen ovale and incidence of pterygoalar bar in 112 dried adult human skulls.



MATERIALS AND METHODS

In this study 112 was adult dry human skulls of unknown sex were used. The skulls were examined from the department of Anatomy, government medical college Aurangabad during the year 2019-2020. The skulls were carefully observed for the variations of foramen ovale at the greater wing of sphenoid bone by naked eyes. The anteroposterior (length) and transverse (width) diameter of foramen ovale was measured by using digital Vernier calliper. Measurements were taken in millimeters. The obtained data was properly recorded and tabulated. The photographs were taken and findings were compared with previous studies by different authors.



RESULT

In the present study 112 dry adult human skulls were used. The shape of the foramen ovale was observed for it’s variations. The oval shaped Foramen was found in majority of skulls, about 148 (66.07%) foramen were oval in shape. Almond shaped foramen was observed in 32 (14.28%) cases. Twenty four, 24 (10.72%) foramen were rounded in shape and 16 (7.15%) were 'D' shaped. Only four (1.78%) skulls showed presence of triangular shaped foramen. All the skulls showed presence of foramen ovale on both sides, none of the skull was with absent foramen ovale. Slit shaped foramen ovale was not observed in any of the skull. Double and confluent foramen ovale was also not found in any skull. (Table no.1)

The mean length of foramen ovale on right side was 7.52+1.15 mm and on left side was 7.7.29+1.06 mm. The maximum length of foramen ovale on right and left side was 10.1mm and 9.7mm respectively. The minimum length of foramen ovale on right side was 5.52mm and on left side was 5.43mm. The mean width of foramen ovale was 4.18+0.78 mm on right side and on left side was 4.28+0.81 mm. The maximum width was 6.56mm and 6.30mm on right and left side respectively. The minimum width was 2.87mm on right side and on left side was 2.5mm. Statistical analysis was done by using paired t test to calculate the difference between right and left side. In all parameters (length and width) comparison between two sides was not significant statistically. (Table no.2) In the present study the bony spur in foramen ovale was present unilaterally in 4 cases. None of the skull shows bilateral presence of bony spur. The complete pterygoalar bar was found unilaterally in seven cases whereas one skull shows incomplete presence of unilateral pterygoalar bar. Bilateral complete pterygoalar bar was present in only one skull.(Table no.3)

Table 1: Variations of Foramen Ovale with percentage

Sr.no

Shape

Number

Percentage

1

Oval

148

66.07%

2

Almond

32

14.28%

3

Round

24

10.72%

4

D shape

16

7.15%

5

Triangular

4

1.78%



Table 2: Measurements of foramen ovale In millimeters (mm) with statistical analysis

Parameter

Right + Left

Mean + SD

(N=224)

Right Side

Mean + SD

(N=112)

Left side

Mean + SD

(N=112)

Paired 't' test

P value

Length

7.41 + 1.11

7.52 + 1.15

7.19 + 1.06

t= 0.186

P>0.05 NS

Width

4.23 + 0.79

4.18 + 0.78

4.28 + 0.81

t= 0.037

P>0.05 NS



Table 3: Incidence of pterygoalar bar in the present study

Sr.no.

Type of pterygoalar bar

Incidence in number

Incidence in percentage

1

Complete unilateral

7

6.25%

2

Complete bilateral

1

0.89%

3

Incomplete unilateral

2

1.78%

4

Incomplete bilateral

0

0

5

Total incidence

10

8.92%

figure 1
Photo 1 Photo 2
figure 2
Photo 3 Photo 4

figure 3
Photo 5 Photo 6

figure 4
Photo 7 Photo 8

figure 5
Photo 9 Photo 10

Photo 1: Bilateral oval shaped Foramen ovale; Photo 2: Bilateral almond shaped Foramen ovale; Photo 3: Oval shaped foramen on right and rounded on left side; Photo 4: Presence of Complete pterygoalar bar; Photo 5: Triangular foramen ovale; Photo 6: Foramen ovale with bony spur; Photo 7: Complete pterygoalar bar present; Photo 8: D shape foramen ovale present; Photo 9: Incomplete unilateral pterygoalar bar; Photo 10: small spur in foramen ovale



DISCUSSION

The position of foramen ovale is very important in different surgical and diagnostic procedures like compression of Gasserion ganglion in trigeminal neuralgia cases, electroenceplalographic study of temporal lobe in the epileptic patients.11 The reason behind variations in shape of foramen ovale were lies in the developmental process.12 The pterygoalar and pterygospinous ligaments devide the foramen ovale into two compartments, due to these ligaments the transcutaneous needle placement into the foramen ovale become very difficult.13 The surgeon should have knowledge of variations of foramen ovale while performing transovale procedures, as the presence of spur, confluent emissary sphenoidal foramen affects the outcome of cannulation.14 The present study shows variations in shape of foramen ovale. The maximum length of Foramen ovale on right side was 10.1mm and minimum length was 5.52mm. The mean length of foramen ovale on right side was 7.52+1.15mm. The maximum length of foramen ovale on left side was 9.7mm and minimum length was 5.43mm. The average length on left side was 7.29+1.06mm. Biswabina Ray et al.7 reported that the mean length of foramen ovale was 7.46+1.41 on right side and 7.01+1.41mm on left side. These findings of Biswabina Ray at al regarding length of foramen ovale are consistent with the findings of present study. Osunwoke et al.15 concluded that the maximum length of foramen ovale was 9.5mm and minimum length was 5mm, these findings are more or less similar to the present study. Arun SK16 reported the maximum length of about 9.8mm and minimum length of about 2.9mm. Landle MK17 stated in fluroscopically assisted laser targetting study of Foramen ovale that the average length on right side and left side was 6.9mm and 6.8 mm respectively and the average width was 3.4mm on right side and 3.8mm on left side. The findings of Arun SK17 and Landle MK17 did not matches with the present study. In the present study the maximum width of foramen ovale was 6.56mm on right side and 6.3mm on left side, whearas the minimum width of foramen ovale was 2.87mm on right side and 2.5mm on left side. The mean width of foramen ovale was 4.18+0.78mm and 4.28+0.81mm on right and left side respectively. These findings of present study regarding width of foramen ovale was found to be higher than that of other studies described by different authors. Lang J18 showed that the average length and width of foramen ovale was 7.2mm and 3.7mm on right and left side respectively. The Biswabina Ray7 stated that the average width of foramen ovale was 3.21+0.02mm on right side and 3.29+0.85mm on left side. The present study observed the ovale shaped (66.07%) foramen in majority of the skulls, this findings was in accordance of Biswabina Ray7 that reported the oval shaped foramen in 61.4% cases. Biswabina et al... found the almond shaped foramen in 34.3%, round shaped foramen in 2.9% and slit like foramen ovale in 1.4% of cases. The present study showed presence of almond shaped foramen in 32(14.28%) cases, rounded foramen in 24(10.72%) cases, D shaped foramen in 16(7.15%) and triangular shaped foramen was noticed in 4(1.78%,) of cases. Daimi SR et al.19 found oval shaped foramen in 29.87%, almond shaped in 10.41%, rounded in 12.52%, slit like in 1.04% and D shaped in 46.16% of cases. Raymond et al.10 noticed bony spur in 4.5% of cases. The study conducted by Ray et al.7 revealed that spur was present in about 3 cases. The present study shows presence of bony spur unilaterally in 4 cases. The pterygoalar bar was noticed in 5 cases by skrzat et al..14 Lepp and sander20 showed presence of osseous bridge in about 8-10% of skulls. About 7.05% unilateral and 0.89% bilateral pterygoalar bar was noticed by chouke and Hodes.21 Kapur et al.22 stated that complete unilateral pterygoalar bar was present in 5% of antolian skulls with lower frequency of bilateral pterygoalar bar. The present study revealed that the complete pterygoalar bar was found unilaterally in 7 cases whearas one skull shows incomplete presence of unilateral pterygoalar bar. Bilateral complete pterygoalar bar was found in only one skull.



CONCLUSION

The present study is of clinical significance to the neurologist in cases of trigeminal neuralgia, aneurysm and in cases of diagnostic ditection of tumours when surgeon planned to approach the middle cranial fossa through foramen ovale. The present study revealed wide variations in morphometry of foramen ovale. The abnormal outgrowth like presence of bony bar, spur may lead to widespread symptoms of ischamia and necrosis.



REFERENCES

  1. Standering S: The Anatomical Basis of Clinical Practice, Gray’s Anatomy, 39th Ed. Elsevier Limited, 2006:460-462.
  2. Sondheimer FK, Basal foramina and canals. In:Newton, TH and Potts DG (Editors). Radiology of the skull and brain. St.Louis, Mosby, 1971.pp287-308.
  3. Kaplan M, Erol FS, Ozveren MF, et al.... Review of complications due to foramen ovale puncture. JJ Clin Neurosci.2007; 14(6): 563-568, doing:10.1016/j.jocn.2005.11.043,indexed in pubmed:17169562.
  4. Williams LS, Schmalfuss IM, Sistrom CL, et al.... MR imaging of the trigeminal ganglion, nerve, and the perineural vascular plexus: naormal appearance and varients with correlation to cadaver specimens. AJNR Am J Neuroradiol. 2003; 24(7):1317-1323, indexed in pubmed: 12917119.
  5. Romanes GJ: Cunningham’s Textbook of Anatomy, Head, Neck and face, 15th Ed. London, Oxford University Press, 1972;106.
  6. Yanagi S: Developmental studies on the foramen rotundum, foramen ovale and foramen spinosum of the human sphenoid bone. The Hokkaido Journal of Medical Science 62(3): 485-496,1987.
  7. Biswabina R, Nirupma G, Supriya G: Anatomic variations of foramen ovale. Kathmandu University Medical Journal 3(1): 64-68, 2005.
  8. Wicsor HG, Siogel AM, Analysis of foramen ovale, electode-recorded seizures and correlation with outcome following amygdalohippocampectomy Epilepsia 1991;32:838-850.
  9. SindouM M, Chavez JM, Saint Pierre G et al.... Percutaneous biopsy of cavernous sinus tumours through the foramrn ovale. Neuroanatomy 1997;40:106-111
  10. Raymond J, Chauruta A and Wysocki J. The morphology and morphometry of the foramina of the greater wing of human sphenoid bone. Folia Morphological. 2005;64:188.
  11. Berge JK, Bergman RA. Variations in size and in symmetry of foramina of the human skull. Clin Anat. 2001;14(6): 406-413, doi: 10.1002/can.1075, indexed in pubmed: 11754234.
  12. Nemzek WR, Brodie HA, Hecht ST, Chong BW, Babcook CJ and Seibert JA. MR, CT and plain film imaging of the developing skull base in fetal specimens. American journal of Neuroradiology. 2000; 21: 1699-1706.
  13. Tubbs RS, May WR Jr, Apaydin N, Shoja MM, Shokouhi G, Loukas M, and Cohen-Gadol A. A Ossification of ligaments near the firamen ovale: an anatomic study with potential clinical significance regarding transcutaneous approaches to the skull base. Neurusurgery. 2009; 65:60-64.
  14. Skrzat J, Walocha J, Zawilinski J. Accessory spine of the foramen ovale. Folia Morphol. 2012; 71(4): 263-266, indexed in pubmed: 23197146.
  15. Osunwoke EA, Mbadugha CC, Orish CAN, Oghenemavwe EL and Ukah CJ. A morphometric study of foramen ovale and foramen spinosum of the human sphenoid bone in the southern Nigerian population. J APPL Biosci. 2010; 26:1631-1635.
  16. Arun S. Kumar, Some observations of the foramina ovale and spinosum of the foramina ovale and spinosum of human sphenoid bone.Vol.55:1.
  17. Landle MK, Walter Grand: Trigeminal neuralgia: Fluroscopically Assisted Laser Targetting of foramen ovale: Technical Note. Minrad International, 2005.
  18. Lang J, Maier R, Schafhauser O: postnatal enlargement of the foramina rotundum, ovale et spinosum and their topographical changes.Anatomischer Anzeiger 156(5): 351-387, 1984.
  19. Diami SR, Siddiqui AU, Gill SS. Analysis of foramen ovale with special emphasis on pterygoalar bar and pterygoalar foramen. Folia Morphol. 2011;70(3): 149-153, indexed in Pubmed: 21866524.
  20. Lepp FH, Sander O. Anatomic radiographic study of ossified pterygospinous and “innominate” ligaments. 1968;Oral Surg Oral Med Oral Pathol, 26: 244-260.
  21. Chouke KS, Hodes PJ. The pterygoalar bar and it’s recognition methods in trigeminal neuralgia. Am J Roentgenol. 1951; 65:180-182.
  22. Kapur E, Dilberovic F, Redzepagic S, Berhamovic E. Variations in the lateral plate of the pterygoid process and the lateral subzygomatic approach to the mandibular nerve. Med Arch, 54: 133-137.
